Quick Draw Detailing Inc. offers full range structural steel detailing from small jobs weighing less than one ton to jobs over 1000 tons and beyond.

Our goal is to take your job from engineer's and architect's drawings and transform it into the comprehensive fabrication and erection drawings that will make your construction process as efficient as possible.  We primarily work on industrial projects but we also work on various other types of structures such as commercial buildings, schools, hospitals, and churches.

Our scope of work typically includes all structural columns, beams, vertical braces, horizontal braces, and girts.  We also frequently design stairs, ladders, and caged ladders and less frequently we detail grating.  Every type of structural steel framing and miscellaneous members is within our detailing experience.

The drawings we produce are created digitally in a high resolution PDF format so that when you receive your drawings they will be clearly legible and easily printed.
